Project description
‘ANASUYA’ presents to you a range of most technically advanced Hand press brakes with all latest features as per international standards.
Side-Well
Made form M.S. plates, vertical and horizontal supports are provided for more strength.
Screw
Made from mild steel square thick threads. Both the ends Are tempered to increase strength and to eliminate wear of screws.
Upper beam
Made from heavy solid plates. All surfaces are surfaced to get accuracy.
V-Block
Made from mild steel and sharpened upto 20 after Sufficient machining. An additional half round die is Supplied as optional accessories if required by customer.
Standard Accessories
- Knikfe
- V-Block Die
- Tommy Bar (2-Nos.)
- Pair Of Lifting Links
Optional Accessories
- Back Gauge
- Screw With Minute Thread
- Half Round Die
- V-Block as per Requirement
- Sheet Support Bracket
Machine Configuration
| Sr No.. | Capacity (Length X Thick) | Stroke of Ram | Knife | V-Block | Half Round |
| 1 | 1500 X 1.2 | 75 | 125 X 12 | 60 X 60 | – |
| 2 | 2000 X 1.2 | 75 | 150 X 16 | 65 X 65 | 125 X 25 |
| 3 | 2000 X 2 | 75 | 150 X 16 | 65 X 65 | 125 X 25 |
| 4 | 2000 X 3.25 | 75 | 150 X 20 | 90 X 90 | – |
| 5 | 2500 X 2 | 100 | 150 X 16 | 65 X 65 | 125 X 25 |
| 6 | 2500 X 3.15 | 100 | 150 X 20 | 90 X 90 | – |
